低烟无卤电缆料造粒机基本成分：（氢氧化铝，氢氧化镁等），树脂粒子（EVA，PE），阻燃剂添加剂粉末（阻燃关联效应剂，润滑剂，抗氧化剂等），肥料颗粒（有机硅母料，等等）的辅助液体（耦合分散剂）。

​低烟无卤电缆料造粒机基本的工艺路线：

阻燃剂和计量饲料添加剂粉末第一高速混合机，并加入添加剂液体，粉末表面耦合分散，表面处理添加树脂，混入混合器或混合器，混合器均匀地进入双锥馈送机后，双顺序之后后机混合造粒。考虑该材料易吸湿的特性，因此，优化造粒的空气填充的敏锐方式。

低烟无卤电缆料造粒机 应用：低烟无卤电缆料，辐照交联低烟无卤无卤电缆，高阻燃电缆料等。

无低烟无卤电缆料造粒机制粒工艺（造粒过程）：

1.捏合机---输送带---锥形强制进料机---两阶段挤出机---热点面对面切割机助手

2.制粒工艺：捏合机---输送带---锥形强制进料机---单螺杆挤出机---热点面对面---切割机助手

低烟无卤电缆料造粒机技术特点：

本机通常用于生产PVC /低烟无毒/氯化聚乙烯/功能母粒的原料，它由主体、锥形器和模面切割系统等将混合材料进料口，将由两个轴后，材料是由一个螺杆挤出的颗粒。被削减的是最终产品，这台机器很容易操作。

昆山供应低烟无卤电缆料造粒机，低烟无卤电缆料生产线







Basic ingredients :resin particles(EVA,PE),flame retardants(aluminium  hydroxide ,magnesium hydroxide ,etc.)additives powder(flame retardant association effect agent ,lubricant ,antioxidant, Etc)fertilizer granules(silicone master batch ,etc)auxiliary liquid (coupling dispersant)



basic processing route:

Flame retardants and metering feed additives powder first high-speed mixer ,and adding additives liquid ,powder surface coupling dispersion ,surface treatment after adding resin ,after mixing into the mixer or mixer ,the mixer evenly into double cone feeding machine ,after the double order machine mixing granulation .considering the characteristics of the material easy to moisture absorption ,therefore ,optimizing the air-filled keen way of granulation.

 Application :low smoke no halogen cable material ,radiation cross-linking low smoke no halogen cables ,high flame retardant cable material ,etc.

1.Granulating process: kneader---conveyor--- conical force feeder---two stage extruder---hot-face cutting assistant machine

2.Granulating process :kneader---conveyor---conical force feeder---single screw extruder---hot-face---Cutting assistant machine







Technical Characteristics:

This machine is normally used produce PVC/LSFH/chloridize polythene/function master batch raw material ,It consists of main body ,conical  feeder   and die-face cutting system etc. Put the mixed material into the feeding inlet .After being pushed in by two shafts ,the material is extruded by a screw .The granules which being cut is the final product ,This machine is easy to operate.





特征：

高科技自动化和流水线作业

优秀的分散效果

高输出和清洁的工作环境

Features:

High technology automation and assembly line work

Excellent dispersion effect

High output and clean working conditions
